TRENDnet TL2-E284 - Page 65

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
7-7
Policed-DSCP - Assign a new DSCP value to the packets.
Policed-Priority - Assign a new 802.1p priority to the packets.
In-Profile Action Value
Specify the new value of above. When rewriting DSCP tag, the possible value
is 0-63; when rewriting the 802.1p priority, the possible value is 0-7.
Out-Profile Action
Specify the action to packets exceed the rate threshold. The options are:
Drop - Drop the packets.
Policy DSCP - Assign a new DSCP value to the packets.
Out-Profile Action
Value
Specify the new value of DSCP tag. The possible value is 0-63.
Click Add to create a new policymap, Reset to clear the value.
Parameter
Description
Policy Map ID
Specify the policymap ID. The possible value is 1-65535.
Classmap ID
Specify which classmap to bind.
Traffic Rate
Set the traffic rate threshold in Kbps for the class map.
In-Profile Action
Specify the action to packets do not exceed the rate threshold. The options
are:
Policed-DSCP - Assign a new DSCP value to the packets.
Policed-Priority - Assign a new 802.1p priority to the packets.
In-Profile Action Value
Specify the new value of above. When rewriting DSCP tag, the possible value
is 0-63; when rewriting the 802.1p priority, the possible value is 0-7.
Out-Profile Action
Specify the action to packets exceed the rate threshold. The options are:
Drop - Drop the packets.
Policy DSCP - Assign a new DSCP value to the packets.
Out-Profile Action
Value
Specify the new value of DSCP tag. The possible value is 0-63.
Click Apply to submit the changes to the policymap, Delete to delete it.
