TRENDnet TL2-E284 - Page 70

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
8-5
Figure 77 – QoS > Egress Algorithm
Parameter
Description
Scheduling Algorithm
Select the algorithm of queue scheduling. The options are:
Strict Priority - The traffic in highest queue always process first.
Weighted RoundRobin - Using weighted round-robin algorithm to handle
packets in priority queues.
Default is Strict Priority.
Click Apply to submit the changes.
