Data exchange

Manual m600 basic 2.6_01 149

Labels

Loading all or individual labels via USB stick

Loading files

Bitmaps

Loading all or individual bitmaps via USB stick

Fonts

Loading all or individual fonts via USB stick

NOTE

Files loaded from an USB stick must be saved previously

in the folder "m600Backup" > bearing the name of the

m600 basic (see Chapter 6.1.4). Standard folders are

used as subfolders.
