Data exchange

150 Manual m600 basic 2.6_01

Loading files Configuration

Loading the installation configuration via USB stick. This can be

transferred to another m600 basic.

NOTE

After one or all fonts has/have been loaded, the system

is restarted once the menu is exited.

NOTE

After a configuration has been loaded, the system is

restarted once the menu is exited.
