Data exchange

Manual m600 basic 2.6_01 159

The m600 basic is restarted.

Software

update

NOTE

If the following message appears after the update, the

m600 basic must be shut off and restarted after 10

seconds.

NOTE

If the following message appears after the restart, the

m600 basic must be shut off and restarted after 10

seconds (version-dependent).

NOTE

To delete active files of the operating system, perform the

update once more.
