Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-220
Exit Sensor (PL17.1.11)
Step Check Yes No
Possible causative parts:
• Exit Sensor (PL17.1.11)
• Exit Sensor Harness Assembly (PL17.1.18)
• Sensor Harness Assembly (PL17.1.23)
• MCU Board (PL18.1.13)
1 Check the Exit Sensor operation
Execute Input Output diagnostic test [071-104], and check
the Exit Sensor operation.
Does the Exit Sensor function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Exit Sensor connection
Check the connection between the Exit Sensor and the MCU
Board.
Are P/J155, P/J151, and P/J15 connected securely?
Go to step 3. Connect P/J155,
P/J151, and
P/J15 securely.
3 Check the continuity between the Exit Sensor and the relay
connector
Is each cable of P/J155<=>P/J151 continuous?
Go to step 4. Replace the Exit
Sensor Harness
Assembly.
4 Check the continuity between the relay connector and the
MCU Board
Is each cable of P/J151<=>P/J15 continuous?
Go to step 5. Replace the
Sensor Harness
Assembly.
5 Check the power to the Exit Sensor (+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J15-1 pin is about +5 VDC.
Replace the Exit
Sensor.
Refer to “+5 VDC
Power FIP” on
page 2-223.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
