YASKAWA Sigma-7 SGD7S Series - Page 159

Tool Function Reference
Digital Operator Fn080
& Σ-7-Series Digital Oper-
ator Operating Manual
(Manual No.: SIEP
S800001 33)
SigmaWin+ Setup - Polarity Detection
Ä Chap. 6.10.4 ‘Using a
Tool Function to Perform
Polarity Detection’
page 158
Use the following procedure to perform polarity detection.
1.
Click the Servo Drive Button in the workspace of the Main Window of the Sig-
maWin+.
2. Select Polarity Detection in the Menu Dialog Box.
ð
The Polarity Detection Dialog Box will be displayed.
3. Click the Continue Button.
Fig. 111: Polarity Detection - Warning
ð
Click the Cancel Button to cancel polarity detection. The Main Window will
return.
Operating Procedure
Sigma-7 Series SERVOPACKs
Basic Functions That Require Setting before Operation
Polarity Detection > Using a Tool Function to Perform Polarity Detection
| | PROFINET Communications - SIEP YEUOC7P 02A Revision 0 | en | 159
