Model SGD7S- 120A
Maximum Applicable Motor Capacity [kW] 1.5
Continuous Output Current [Arms] 11.6
Instantaneous Maximum Output Current [Arms] 28
Main Circuit Power Supply 200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms]
*
16
Control Power Supply 200 VAC to 240 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms]
*
0.25
Power Supply Capacity [kVA]
*
4.0
Power Loss
*
Main Circuit Power Loss [W] 71.8
Control Circuit Power Loss [W] 16
Built-in Regenerative Resistor
Power Loss [W]
12
Total Power Loss [W] 103.8
Regenerative
Resistor
Built-In Regen-
erative Resistor
Resistance [Ω] 12
Capacity [W] 60
Minimum Allowable External
Resistance [Ω]
12
Overvoltage Category III
* This is the net value at the rated load.
3.2.2 SERVOPACK Overload Protection Characteristics
The overload detection level is set for hot start conditions with a SERVOPACK sur-
rounding air temperature of 55°C.
An overload alarm (A.710 or A.720) will occur if overload operation that exceeds the over-
load protection characteristics shown in the following diagram (i.e., operation on the right
side of the applicable line) is performed.
The actual overload detection level will be the detection level of the connected SERVO-
PACK or Servomotor that has the lower overload protection characteristics.
In most cases, that will be the overload protection characteristics of the Servomotor.
Single-Phase, 200 VAC
Sigma-7 Series SERVOPACKs
Selecting a SERVOPACK
Ratings and Specifications > SERVOPACK Overload Protection Characteristics
| | PROFINET Communications - SIEP YEUOC7P 02A Revision 0 | en | 59
