SigmaWin+ SERVOPACK
Menu
Dialog
Box
Button
Name [Unit] Un
No.
Name [Unit]
Active Gain Monitor Un014 Effective Gain Monitor (gain set-
tings 1 = 1, gain settings 2 = 2)
Safety I/O Signal Monitor Un015 Safety I/O Signal Monitor
Input
Signal
Monitor
Input Signal Monitor Un005 Input Signal Monitor
Output
Signal
Monitor
Output Signal Monitor Un006 Output Signal Monitor
Service
Life Mon-
itor
Installation Environment
Monitor − SERVOPACK
Un025 SERVOPACK Installation Envi-
ronment Monitor [%]
Installation Environment
Monitor − Servomotor
*2
Un026
*2
Servomotor Installation Environ-
ment Monitor [%]
Service Life Prediction Mon-
itor − Built-in Fan
Un027 Built-in Fan Remaining Life Ratio
[%]
Service Life Prediction Mon-
itor − Capacitor
Un028 Capacitor Remaining Life Ratio
[%]
Service Life Prediction Mon-
itor − Surge Prevention Cir-
cuit
Un029 Surge Prevention Circuit
Remaining Life Ratio [%]
Service Life Prediction Mon-
itor − Dynamic Brake Circuit
Un02A
*3
Dynamic Brake Circuit Remaining
Life Ratio [%]
Service Life Prediction Mon-
itor − Built-in Brake Relay
Un036 Built-in Brake Relay Remaining
Life Ratio [%]
Product
Information
Motor − Resolution Un084 Linear Encoder Pitch (Scale pitch
= Un084 × 10
Un085
[pm])
Un085 Linear Encoder Pitch Exponent
(Scale pitch = Un084 × 10
Un085
[pm])
– – Un020
Rated Motor Speed [min
-1
]
– Un021
Maximum Motor Speed [min
-1
]
*1.
You can use Un010 to monitor the upper limit setting for the maximum motor speed or the
upper limit setting for the encoder output resolution.
You can monitor the upper limit of the encoder output resolution setting (Pn281) for the
current maximum motor speed setting (Pn385), or you can monitor the upper limit of the
maximum motor speed setting for the current encoder output resolution setting.
Select which signal to monitor with Pn080 = n.X (Calculation Method for Maximum
Speed or Divided Output Pulses).
n If Pn080 = n.0, the encoder output resolution (Pn281) that can be set is dis-
played.
n If Pn080 = n.1, the maximum motor speed (Pn385) that can be set is displayed
in mm/s.
Sigma-7 Series SERVOPACKs
Appendices
Corresponding SERVOPACK and SigmaWin+ Function Names > Corresponding SERVOPACK Monitor Display Function Names
