Inspecting, mechanical stops
Use this procedure to inspect the additional mechanical stops.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
Shown in figure Location of
mechanical stops on page 130.
Check the additional stops for damage.2
Make sure stops are properly attached.3
Correct tightening torque, mechanical stops:
• Axis-1 = 115 Nm
Art. no. is specified in Required
equipment on page 130.
If any damage is detected, the mechanical stops
must be replaced!
Correct attachment screws:
• M12x70 quality 12.9 Gleitmo 603 (2 pcs per
additional mechanical stop)
4
3HAC044266-001 Revision: - 131
© Copyright 2013 ABB. All rights reserved.
3 Maintenance
3.3.11 Inspecting, additional mechanical stops
Continued
