Concluding procedure
NoteAction
xx1300000490
Refit the heat protection plate to the axis-
5 motor.
1
xx1300000489
Secure the motor cables to the heat protec-
tion plate with a cable tie.
2
xx1300000596
Check that the cable harness will be placed
in a way that it will not be damaged when
the wrist cover is fitted.
3
Continues on next page
292 3HAC044266-001 Revision: -
© Copyright 2013 ABB. All rights reserved.
4 Repair
4.5.2 Replacing the wrist
Continued
