Fiber Optic Cables and Accessories
MPO24 Port MPOPort Description LCPort Description
6 Tx6 Rx6
7 Tx7 Rx7
8 Tx8 Rx8
9 Tx9 Rx9
10 Tx10 Rx10
11 Tx11 Rx11
12 Tx12 Rx12
13 Rx1 Tx1
14 Rx2 Tx2
15 Rx3 Tx3
16 Rx4 Tx4
17 Rx5 Tx5
18 Rx6 Tx6
19 Rx7 Tx7
20 Rx8 Tx8
21 Rx9 Tx9
22 Rx10 Tx10
23 Rx11 Tx11
24 Rx12 Tx12
l Cabling Diagram with 48Optical Filter Channels
l Cabling Diagram with 128Optical Filter Channels
l Handling Fiber-Optic Cables
l Laser and LED Safety Guidelines and Warnings
