Installing Side Air Covers
Figure 49: Side Air Cover Installed
6. Repeat Steps 2 through 5 for the air vent on the bottom of this side.
7. Repeat Steps 2 through 6 for the opposite side of the shelf.
l Installation Overview — SH12 and SH4R Shelves
l Clearance Requirements
l Side Air Covers
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 193
