Connecting DC Power to the SH12 Shelf
Carefully note the polarity of any power connection. If the supply voltage
is applied with the wrong polarity, reverse polarity protection ensures that
no current flows in the wrong direction and therefore there will be no
power at the PSM output.
12. Based on your configuration, identify the Power B input power connector(s) you will
use and Repeat Steps 6 through 11.
13. Use a multimeter to check that a voltage level of –48 VDC is available at the PDU.
14. Reinstall all fuses into the PDU.
15. Turn the PDU Power A circuit breaker to the ON position.
16. Confirm that the PDU has power. The green power indicator should be lit.
As soon as power is up, the ECM-2 starts booting. The Mod LED of the PSM-DC
(Power A)should turn green, indicating that the units are functioning properly.
The FTM-2s should start working, one after another and the fan status LED should
turn green. This also indicates that the FTMs are functioning properly. In addition, the
power LEDs of all modules installed in the shelf should turn green.
If the Mod LED of the PSM-DC is off, then no power is being supplied to
the unit. In case of an error, the power LED turns red. For troubleshooting
information, see the FSP 3000 C Troubleshooting Guide or contact ADVA
Optical Networking for technical assistance.
17. Turn on the PDU Power B circuit breaker and check the power LEDs.
As soon as power is up, the ECM-2 starts booting. This is indicated by the slot LEDs
all blinking yellow. The Mod LED of the PSM-DC (Power B)should turn green,
indicating that the units are functioning properly.
The FTM-2s should start working, one after another and the Svc LED should turn
green. This also indicates that the FTMs are functioning properly. In addition, the
Mod LEDs of all modules installed in the shelf should turn green.
If the Mod LED of the PSM-DC is off, then no power is being supplied to
the unit. In case of an error, the Mod LED turns red. For troubleshooting
information, see the FSP 3000 C Troubleshooting Guide or contact ADVA
Optical Networking for technical assistance.
18. If necessary, repeat this procedure for each SH12 mounted in the rack.
l DCPower Source Requirements
l DC Power Cable Specifications
l Shortening and Assembling DCPower Cables
l Electrical Safety Guidelines and Warnings
l In Case of Electrical Accident
l FSP 3000 C Troubleshooting Guide
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 239
