Use the drop-down menu to specify the MEG level at which the MEP exists.
CCM tab page
The CCM tab page contains the following parameter:
CCM interval
Use the drop-down menu to specify the frequency at which CCMs are
transmitted and expected to be received.
LBM tab page
The LBM tab page contains the following parameters:
Optional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLV and Test TLV. If you select one of the TLV types, fields for
specifying the ID will appear.
Length
Only available if a Data or Test TLV type has been selected. Allows you to
specify the length of the TLV.
Value
Only available if a Data or Test TLV type has been selected. Allows you to
specify the value of the TLV. Note that for the Data TLV type, this field is an
entry field where you open an editor and type the value; for the Test TLV
type, it is a drop-down menu.
LTM tab page
The LTM tab page contains the following parameters:
TTL
Allows you to specify a TTL value. Used to indicate whether or not an LTM
should be terminated by the receiver.
Trans ID
Allows you to specify the transaction number for the LTM.
TST tab page
The TST tab page contains the following parameters:
Frames to send
Allows you to specify the number of frames to be transmitted.
Rate
Use the drop-down menu to select the rate at which frames are transmitted.
Optional TLV
Use the drop-down menu to select the Test TLV type, if relevant. Fields for
specifying the length and value will then appear.
Length
Only available if the Test TLV type has been selected. Allows you to specify
the length of the TLV.
Value
Only available if the Test TLV type has been selected. Use the drop-down
menu to select the value of the TLV.
MCC tab page
The MCC tab page contains the following parameters:
