OUI
Allows you to specify the Organizationally Unique Identifier for the
organization defining a specific format and meaning of ETH-MCC.
Data
Allows you to specify any required additional information. The type of
information depends on the specific application of ETH-MCC.
LCK tab page
The LCK tab page contains the following parameters:
Client MEG level
Allows you to specify the MEG level of the client MEG.
LCK rate
Use the drop-down list to select the rate of the LCK frames being transmitted.
AIS tab page
The AIS tab page contains the following parameters:
Client MEG level
Allows you to specify the MEG level of the client MEG.
AIS rate
Use the drop-down menu to select the rate of the AIS frames being
transmitted.
DM1 tab page
The DM1 tab page contains the following parameters:
Type
Use the drop-down menu to select the relevant operation type (On-demand
operation or Proactive operation). The same DM1 frame format can be
used for both.
Rate
Use the drop-down menu to select the rate at which DM1 frames are
transmitted.
Frames to send
Allows you to specify the number of frames to transmit.
Optional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLV and Test TLV. If you select one of the TLV types, fields for
specifying the ID will appear.
Length
Only available if a Data TLV type has been selected. Allows you to specify
the length of the TLV.
Value
Only available if a Data TLV type has been selected. Allows you to specify
the value of the TLV. Note that for the Data TLV type, this field is an entry
field where you open an editor and type the value.
ID
Only available if a Test TLV type has been selected. Allows you to specify
the value of the ID.
DMM tab page
