Content
Alarm Insertion
Error Insertion
Link Detection
Login Detection
Pattern Detection
Transceiver
BER Test
Reflector mode
Port mode
Line rate
Transmitter Clock
Content
Pattern
CPRI Link
FOX, ALL5555, PRBS 9, PRBS 11, PRBS 15, PRBS 20, PRBS 23, PRBS 29, PRBS
31, BHFTEST, BCRPAT, BJTPAT, BSPAT, USER_32, ZERO
Item
Link reset, Link reset response, Not optional, Offline
Item
Bit, Symbol, R_RDY, CRC
Insertion timing
Manual, Burst
Signal Present, Sync Acquired, Link Status
Login State, Fabric Login, Port Login
Traffic, Pattern Sync, Pattern Error
Module Present
Transceiver Information
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
BERT:
Pattern bit count, Pattern errors, Frame loss, Frame loss seconds, Pattern
loss seconds, Jitter, Latency, Service disruption
Symbol Errors
Ordered Sets:
R_RDY, LR, LRR, NOS, OLS
Traffic:
Frames, Bytes
Errors:
IFG, CRC, Symbol, CRD, Terminate, Errored
Line rate, Frame rate, Throughput
Size Distribution
Supports Reflector application.
11.3.5 CPRI/OBSAI
Off, Normal, Through
CPRI: 614.4 Mbps, 1228.8 Mbps, 2457.6 Mbps, 3072.0 Mbps, 4915.2 Mbps,
6144.0 Mbps, 9830.4 Mbps, 10137.6 Mbps
OBSAI: 768 Mbps, 1536 Mbps, 3072.0 Mbps, 6144.0 Mbps
Reference Clock
Internal clock
External clock
BITS
SETS
2MHz
10MHz
GPS
Received clock
Unframed, CPRI Link
PRBS 15, PRBS 20, PRBS 23, PRBS 29, PRBS 31, User 32 bit, OFF
Start up
Enabled, Disabled
Role
Master, Slave
Protocol version
1, 2
HDLC rate
