INTERIOR TRIM 9G–11
DAEWOO M-150 BL2
D110A501
LOWER B–PILLAR TRIM PANEL
Removal Procedure
1. Remove the bolt on the lower B–pillar trim panel.
D Remove the bolt (1).
D Remove the spacer and the spring washer (2).
D Remove the plastic protector from the seat belt an-
chor.
D109E559
2. Pry off the lower B–pillar trim panel.
D109E560
Installation Procedure
1. Install the lower B–pillar trim panel.
2. Install the bolt on the lower B–piller trim panel. Refer
to Section 8A, Seat Belts.
D109E561
C–PILLAR TRIM PANEL
Removal Procedure
1. Disconnect the negative battery cable.
2. Open the tailgate.
3. Disconnect the rear speaker electrical connector.
To Next Page
