1E–42 ENGINE ELECTRICAL
DAEWOO M-150 BL2
BATTERY SPECIFICATIONS
Application Description Unit Standard Limit
Battery Type – MF –
Capacity AH 35 –
Cold Cranking Amps CCA 246 –
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb-Ft Lb-In
Distributor Bolts 10–16 – 89–142
Battery Retainer Clamp–to–Battery Rod Nuts 6–8 – 53–71
Battery Carrier Tray Bolts 9–12 – 80–106
Battery Cable Nuts 9–12 – 80–106
Starter field Connector Nut 9–12 – 80–106
Starter Through–Bolts 4–6 – 35–53
Starter Mounting Bolts 55–65 41–48 –
Starter Solenoid Assembly Screws 6–8 – 53–71
Starter Solenoid Nuts 9–12 – 80–106
Spark Plug 20–30 15–22 –
Generator Through–Bolts 4–6 – 35–53
Generator Drive End Nut 80–110 59–81 –
Generator Battery Lead Connector Nut 4–7 – 35–62
Generator Bearing Plate Bolt 6–8 – 53–71
Generator Brush Holder / Rectifier Screw 9–12 – 80–106
Generator Belt Tension Adjusting Bolt 18–28 13–21 –
Generator Shackle Bracket Bolt 45–55 33–41 –
Generator Lower Bracket–to–Generator Bolt/Nut 18–28 13–21 –
Ground Bolt 35–41 26–30 –
Ignition Coil Screw 4–7 – 35–62
Ignition Coil Bracket Bolt 9–12 – 80–106
