7A–20 HEATING AND VENTILATION SYSTEM
DAEWOO M-150 BL2
D108A507
BLOWER MOTOR AND COOLING
HOSE
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the blower motor cooling hose.
D108A508
2. Remove the blower motor.
D Disconnect the motor electrical connector (1).
D Turn the blower motor (2).
D108A509
Installation Procedure
1. Install the blower motor by turning the motor clock-
wise.
2. Connect the motor electrical connector.
3. Install the blower motor cooling hose.
D108A510
BLOWER RESISTOR
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the blower resistor.
D Disconnect the blower resistor connector (1).
D Remove the screws (2).
