9D –10 WIPERS/WASHER SYSTEMS
DAEWOO M-150 BL2
D19D533A
1.5–2.0 NSm
Installation Procedure
1. Install the wiper linkage with the wiper linkage nuts.
Tighten
Tighten the wiper linkage nuts to 1.5–2.0 NSm (13–18
lb-in).
a. Wiper linkage nut.
2. Install the wiper motor linkage ball.
3. Install the cowl vent grille. Refer to Section 9R, Body
Front End.
4. Install the windshield wiper arms. Refer to ”Wind-
shield Wiper Arm” in this section.
D109D534
WINDSHIELD WIPER BLADE
Removal Procedure
1. Pull the wiper blade off the arm by pushing the wiper
blade retaining clip (1).
D109D535
Installation Procedure
1. Install the wiper blade to the arm.
D109D536
WASHER RESERVOIR
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the washer reservoir inlet.
D Remove the bolt (1).
D Remove the washer reservoir inlet (2).
To Next Page
