9G –12 INTERIOR TRIM
DAEWOO M-150 BL2
D109E562
4. Remove the rear parcel side shelf. Refer to “Rear
Parcel Side Shelf” in this section.
5. Remove the rear seatback.
6. Remove the rear seat belt bolt on the C–pillar trim
panel. Refer to Section 8A, Seat Belts.
7. Pry off the C–pillar trim panel.
D Pry off the C–pillar trim panel by hands (1).
D109E563
Installation Procedure
1. Install the C–pillar trim panel.
2. Install the rear seat belt bolt on the C–pillar trim panel.
Refer to Section 8A, Seat Belts.
3. Install the rear seatback.
4. Install the rear parcel side shelf. Refer to “Rear Parcel
Side Shelf” in this section.
5. Connect the rear speaker connector.
6. Connect the negative battery cable.
D109E564
REAR PARCEL SHELF
Removal Procedure
1. Open the tailgate.
2. Remove the rear parcel shelf (1).
D109E565
Installation Procedure
1. Install the rear parcel shelf.
