5B–22 FIVE-SPEED MANUAL TRANSAXLE
DAEWOO M-150 BL2
D103B540
Installation Procedure
1. Install in the reverse order of removal.
2. Push the cables toward the engine compartment
through dash panel’s hole slightly.
3. Position the cables on the select and the shift lever.
D13B5411
4. Connect the transaxle side select and shift control
cable.
5. Connect the gear shift lever side shift control cable.
6. Connect the gear shift lever side select control cable.
D Insert the select control cable eye ring to the select
arm pin (1).
D Install the selector lever control cable clip (2).
D Install the select control cable to gear shift lever
bracket with E–ring (3).
D Insert a driver to the select arm adjustment hole to
prevent the movement of gear shift lever in NEU-
TRAL (4).
7. Tighten the adjust nuts.
Tighten
Tighten the select cable adjust nut to 8–12 NSm
(71–106 lb-in).
D103B543
GEAR SHIFT CONTROL LEVER
Removal Procedure
1. Remove the floor console. Refer to Section 9G, Inte-
rior Trim.
2. Disconnect the select and shift control cable. Refer to
“Gear Shift control cable” in this section.
3. Remove the gear shift control lever assembly.
D Remove the bolts (1).
D Remove the gear shift control lever assembly (2).
D Remove the gear shift lever sensor connector.
(If equipped with auto clutch).
