HYDRAULIC BRAKES 4A–9
DAEWOO M-150 BL2
D107A530
BRAKE HOSE (REAR)
Removal Procedure
1. Remove the wheels. Refer to Section 2E, Tires and
Wheels.
2. Remove the brake hose.
D Remove the fittings (1).
D Remove the E–rings (2).
D Plug the opening in the brake pipe to prevent fluid
loss or contamination.
D17A531A
Installation Procedure
1. Connect the brake lines to the brake hose.
2. Install the fitting and E–rings.
Tighten
Tighten the fitting to 16 NSm (12 lb-ft).
Important: Use only Daewoo recommended brake fluid.
3. Bleed the brake system. Refer to “Manual Bleeding
the Brakes” in this section.
4. Check the brake system for leaks.
5. Install the wheels. Refer to Section 2E, Tires and
Wheels.
D107A523
STOPLAMP SWITCH
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the stoplamp switch.
D Disconnect the connector (1).
D Turn the stoplamp switch (2).
D107A524
Installation Procedure
1. Install the stoplamp switch.
2. Connect the electrical connector.
3. Connect the negative battery cable.
Important: After installing the stoplamp switch, pull the
lever completely.
