FRONT SUSPENSION 2C–7
DAEWOO M-150 BL2
REPAIR INSTRUCTIONS
ON–VEHICLE SERVICE
D16B501A
STRUT ASSEMBLY
Removal Procedure
1. Open the hood.
2. Remove the top of the strut assembly at passenger
seat side.
D For vehicle with power steering, remove the power
steering fluid reservoir (1).
D Remove the nuts (2).
D16B502A
3. Remove the top of the strut assembly at driver side.
D Remove the bolt and the fuse box (1, 2).
D Remove the nuts (3).
D106B503
4. Remove the lower of the strut assembly.
D Raise and suitably support the vehicle.
D Remove the wheel. Refer to Section 2E, Tires and
Wheels.
D Remove the ABS front speed sensor electrical wire
from the bracket, if applicable (1).
D Disconnect the brake hose from the bracket (2).
D Remove the strut bracket bolts (3).
5. Remove the strut bracket assembly from the vehicle.
To Next Page
