BODY FRONT END 9R–5
DAEWOO M-150 BL2
D109C523
2. Install the cowl vent grille with the screws and the
clips.
3. Install the wiper arm assembly. Refer to Section 9D,
Wiper/Washer Systems.
D109C524
HOOD
Removal Procedure
Important: Install the protective coverings over the
fenders and the windshield in order to prevent damage
to the paint, the glass and the moldings when you are
removing and installing the hood.
1. Raise and support the hood.
2. Remove the hood.
D Remove the bolts (1).
D Remove the hood (2).
D109C525
Installation Procedure
Notice: Dissimilar metals in direct contact with each
other may corrode rapidly. Make sure to use the correct
fasteners to prevent premature corrosion.
1. Install the hood with the bolts.
2. Inspect the hood for proper alignment.
D109C526
HOOD HINGE
Removal Procedure
1. Remove the hood. Refer to “Hood” in this section.
2. Take off the cowl vent grille.
D Remove the screws after removing the upper caps
(1).
D Remove the retaining screw on the cowl vent grille
(2).
D Take off the cowl vent grill (3).
To Next Page
