1E–18 ENGINE ELECTRICAL
DAEWOO M-150 BL2
D102E517
IGNITION COIL
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the ignition wires and ignition coil connec-
tor.
D Disconnect the ignition wire (1).
D Disconnect the ignition coil connector by pushing
the connector’s lock(2).
D102E518
3. Remove the ignition coil.
D Remove the screws (1).
D Remove the ignition coil (2).
D12E519A
4–7 NSm
Installation Procedure
1. Install in the reverse order of removal.
2. Install the ignition coil screws.
Tighten
Tighten the ignition coil screws to 4–7 NSm (35–62 lb-
in).
