Daewoo MATIZ - 9 B-2; CHMSL Mounting Bracket; License Plate Lamps

9B–12 LIGHTING SYSTEMS
DAEWOO M-150 BL2
D209B102
CHMSL MOUNTING BRACKET
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the center high–mounted stoplamp
(CHMSL). Refer to “Center High–Mounted Stoplamp”
in this section.
3. Remove the rear window wiper motor assembly. Re-
fer to Section 9D, Wipers/Washer Systems.
4. Remove the CHMSL mounting bracket.
D Remove the bolts (1).
D Remove the CHMSL mounting bracket (2).
D209B103
Installation Procedure
1. Install the CHMSL mounting bracket with the bolts.
2. Install the rear window wiper motor assembly. Refer
to Section 9D, Wipers/Washer Systems.
3 .Install the CHMSL. Refer to “Center High–Mounted
Stoplamp” in this section.
4. Connect the negative battery cable.
D19D510A
LICENSE PLATE LAMPS
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the license plate lamp from the tailgate han-
dle.
D Remove the screws (1).
D Draw out the license plate lamp (2).
D Remove the license plate lamp bulb (3).
D19D511A
3. Remove the rear window wiper motor assembly. Re-
fer to Section 9D, Wipers/Washer Systems.
4. Disconnect the electrical connector in the tailgate.
5. Remove the tailgate handle. Refer to Section 9M, Ex-
terior Trim.
6. Remove the license plate lamp socket.
D Remove the socket (1).
