HEATING AND VENTILATION SYSTEM 7A–21
DAEWOO M-150 BL2
D108A511
Installation Procedure
1. Install the blower resistor with the retaining screws.
2. Connect the blower resistor connector.
D108A512
BLOWER MOTOR SWITCH
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Removal Procedure
1. Remove the control assembly. Refer to “Control As-
sembly and Control Cables” in this section.
2. Remove the blower motor switch.
D Remove the switch knob (1).
D108A513
D Remove the blower motor switch retaining screw
(2).
D Turn the blower motor switch anticlockwise (3).
D108A514
Installation Procedure
1. Install the blower motor switch with the screw.
2. Install the switch knob.
3. Install the control assembly. Refer to “Control Assem-
bly and Control Cables” in this section.
