SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B–25
DAEWOO M-150 BL2
DTC 06 – Passenger Firing Circuit, Resistance Too Low
Step
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Action
Value(s)
Yes
No
ÁÁ
ÁÁ
ÁÁ
ÁÁ
1
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1. Disconnect the negative battery cable.
2. Connect an ohmmeter to the terminals of the
wiring harness connector for the passenger
airbag module on the SDM side of the connector.
D Refer to ‘‘Diagnostic Illustration 8’’ in this
section.
Does the ohmmeter show the specified value?
ÁÁÁ
ÁÁÁ
ÁÁÁ
ÁÁÁ
∞
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
Go to Step 2
ÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁ
Go to Step 4
ÁÁ
ÁÁ
ÁÁ
ÁÁ
2
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1. Replace the SDM.
2. Reconnect the negative battery cable.
3. Set the scan tool to CODE ERASE.
4. Do the diagnostic system check.
Does the code 06 still show as a current fault?
ÁÁÁ
ÁÁÁ
ÁÁÁ
ÁÁÁ
–
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
Go to Step 3
ÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁ
System OK
ÁÁ
3
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1. Replace the passenger airbag module.
2. Reconnect the negative battery cable.
Is the repair complete?
ÁÁÁ
–
ÁÁÁÁÁ
Go to
Diagnostic
System Check
ÁÁÁÁ
–
ÁÁ
ÁÁ
ÁÁ
4
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
1. Replace the supplemental inflatable restraints
(SIR) wiring harness.
2. Reconnect the negative battery cable.
Is the repair complete?
ÁÁÁ
ÁÁÁ
ÁÁÁ
–
ÁÁÁÁÁ
ÁÁÁÁÁ
ÁÁÁÁÁ
Go to
Diagnostic
System Check
ÁÁÁÁ
ÁÁÁÁ
ÁÁÁÁ
–
