ENGINE CONTROLS 1F–45
DAEWOO M-150 BL2
IGNITION SYSTEM CHECK
Circuit Description
The Electronic Ignition (EI) system uses a waste spark
method of spark distribution. In this type of EI system,
the Crankshaft Position (CKP) sensor is mounted to the
oil pump near a slotted wheel that is a part of the crank-
shaft pulley. The CKP sensor sends reference pulses to
the Engine Control Module (ECM). The ECM then trig-
gers the EI system ignition coil. Each cylinder is individu-
al with coil per cylinder in sequence.
This leaves the remainder of the high voltage to be used
to fire the spark plug in the cylinder on its compression
stroke. Since the CKP sensor is in a fixed position, tim-
ing adjustments are not possible or needed.
Ignition System Check
Caution: Use only electrically insulated pliers when
handling ignition wires with the engine running to
prevent an electrical shock.
Step Action Value(s) Yes No
1
1. Remove the spark plugs.
2. Inspect for wet spark plugs, cracks, wear,
improper gap, burned electrodes, or heavy
deposits.
3. Replace the spark plugs as needed.
Is the repair complete?
–
System OK Go to Step 2
2
Check for the presence of spark from all of the
ignition wires while cranking the engine.
Is spark present from all of the ignition wires?
–
System OK Go to Step 3
3
1. Measure the resistance of the ignition wires.
2. Replace any ignition wire(s) with a resistance
above the value specified.
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires? 30000 Ω System OK Go to Step 4
4
Is spark present from at least one of the ignition
wires, but not all of the ignition wires?
Go to Step 5 Go to Step 12
5
1. Turn the ignition OFF.
2. Disconnect the Electronic Ignition (EI) system
ignition coil connector.
3. While cranking the engine, measure the voltage
at the EI system ignition coil connector terminal 1.
Does the voltage fluctuate within the values
specified? 0.2–2.0 V Go to Step 8 Go to Step 6
6
Check for an open in the wire from EI system
ignition coil connector terminal 1 to the Engine
Control Module (ECM) connector terminal 66.
Is the problem found?
–
Go to Step 7 Go to Step 11
7
1. Repair the wiring as needed.
2. Connect the EI system ignition coil connector.
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires?
–
System OK
–
8
While cranking the engine, measure the voltage at
the EI system ignition coil connector terminal 2.
Does the voltage fluctuate within the values
specified? 0.2–2.0 V Go to Step 10 Go to Step 9
