1F–46 ENGINE CONTROLS
DAEWOO M-150 BL2
Ignition System Check (Cont’d)
Step Action Value(s) Yes No
9
Check for an open in the wire from EI system
ignition coil connector terminal 2 to the Engine
Control Module (ECM) connector terminal 1.
Is the problem found?
–
Go to Step 7 Go to Step 11
10
1. Replace the EI system ignition coil.
2. Connect the EI system ignition coil connector.
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires?
–
System OK
–
11
1. Replace the ECM.
2. Connect the EI system ignition coil connector.
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires?
–
System OK
–
12
1. Turn the ignition OFF.
2. Disconnect the crankshaft position (CKP) sensor
connector.
3. Measure the resistance between the CKP sensor
terminals 1 and 2.
Is the resistance within the value specified?
4. Measure the resistance between following
terminals.
D Terminals 1 and 3 of CKP sensor.
D Terminals 2 and 3 of CKP sensor.
Is the resistance within the value specified?
400–600 Ω
∞ Go to Step 14 Go to Step 13
13
Replace the crankshaft position sensor.
Is the repair complete?
–
System OK
–
14
1. Turn the ignition ON.
2. Measure the voltage between the CKP sensor
connector terminals 1 and 3.
Is the voltage within the value specified? 0.95–1.10 V Go to Step 20 Go to Step 15
15
Measure the voltage between the CKP sensor
connector terminal 1 and ground.
Is the voltage within the value specified? 0.95–1.10 V Go to Step 18 Go to Step 16
16
Check the wire between the CKP sensor connector
terminal 1 and the ECM connector terminal 54 for an
open or short.
Is the problem found?
–
Go to Step 17 Go to Step 10
17
Repair the wire between the CKP sensor connector
terminal 1 and the ECM connector terminal 54.
Is the repair complete?
–
System OK
–
18
Check the wire between the CKP sensor connector
terminal 3 and ground for an open or short.
Is the problem found?
–
Go to Step 19 Go to Step 11
19
Repair the wire between the CKP sensor connector
terminal 3 and ground.
Is the repair complete?
–
System OK
–
20
1. Turn the ignition ON.
2. Measure the voltage between the CKP sensor
connector terminals 2 and 3.
Is the voltage within the value specified? 0.95–1.10 V Go to Step 24 Go to Step 21
To Next Page
