2C –6 FRONT SUSPENSION
DAEWOO M-150 BL2
FRONT WHEEL BEARING
Bearing Axial End Play Inspection
D107B303
1. Lift and suitably support the vehicle.
2. Inspect the end play of the bearing.
3. If excessive play is defeeted, free shoes from the disc
or remove the calipers.
4. Check the standard torque of the drive nut (spec. :
210 NSm (155 lb-ft)).
5. Check the bearing end play according to the following
method.
D Place a dial guage against the disc surface, grasp
the disc.
D Using a push–pull movement, note gage readings.
Specification
0.130mm
or less
(0.005 in)
Standard tighting torque
of drive shaft nut :
210 NSm (155 lb-ft)
6. If the axial end play of the front wheel bearing exceed
0.130mm torque the drive shaft nut successively
(Max. allowance : 240 NSm (177 lb-ft))
7. Check the axial end play again.
8. If the axial end play is above spec., replace the front
wheel bearing.
