9B–10 LIGHTING SYSTEMS
DAEWOO M-150 BL2
D209B100
5. Remove the front fog lamp.
D Remove the screws (1).
D Disconnect the electrical connector (2).
D Remove the front fog lamp (3).
D209B101
Installation Procedure
1. Install the front fog lamp with the screws.
2. Connect the front fog lamp connector.
3. Install the front wheelhouse splash shields with the
clips and the bolts.
4. Install the front wheels.
5. Lower the vehicle.
6. Connect the negative battery cable.
D19D508C
REAR FOG/BACKUP LAMP(S)
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the taillamp assembly. Refer to “Taillamps
Assembly” in this section.
3. Remove the bulb(s).
D19D509A
Installation Procedure
1. Install the bulb(s).
2. Install the taillamp assembly. Refer to “Taillamps As-
sembly” in this section.
3. Connect the negative battery cable.
