Daewoo MATIZ - Generator (B-Type: DAC)

ENGINE ELECTRICAL 1E–29
DAEWOO M-150 BL2
D12E740A
4–6 NSm
80–110 NSm
D Tighten the generator pulley nut to 80–110 NSm
(59–81 lb-ft) (d).
D Tighten the through-bolts to 4–6 NSm (35–53 lb-in)
(e).
D102E741
GENERATOR (B-TYPE: DAC)
Disassembly Procedure
1. Remove the generator. Refer to “Generator” in this
section.
2. Remove the cover from the generator.
D Remove the battery positive terminal nut (1).
D Remove the cover (2).
a. Cover.
D102E742
3. Remove the regulator / brush holder / rectifier assem-
bly.
D Remove the stator coil lead and rectifier diode lead
connections (1).
D102E743
D Remove the rectifier bolts (2).
D Remove the rectifier / regulator screw (3).
D Remove the brush holder / regulator screw (4).
D Remove the regulator screw (5).
D Remove the regulator / brush holder / rectifier as-
sembly (6).
