Daewoo MATIZ - Windshield Washer Nozzle; Rear Window Washer Nozzle

9D –12 WIPERS/WASHER SYSTEMS
DAEWOO M-150 BL2
D109D539
Installation Procedure
1. Install the wiper motor to the washer reservoir assem-
bly.
2. Install the washer reservoir assembly.
Refer to “Washer Reservoir” in this section.
3. Connect the negative battery cable.
4. Fill the washer reservoir.
D109D541
WINDSHIELD WASHER NOZZLE
Removal Procedure
1. Remove the cowl vent grille. Refer to Section 9R,
Body Front End.
2. Remove the washer nozzle from the cowl vent grille.
D Disconnect the washer nozzle hose (1).
D Remove the washer nozzle (2).
D109D542
Installation Procedure
1. Install the washer nozzle to the cowl vent grille.
2. Install the washer nozzle hose to the washer nozzle.
3. Install the cowl vent grille. Refer to Sec-
tion 9R, Body Front End.
D109D543
REAR WINDOW WASHER NOZZLE
Removal Procedure
1. Remove the washer nozzle from the wiper arm.
D Disconnect the washer nozzle hose (1).
D Remove the washer nozzle (2).
