4B –6 MASTER CYLINDER
DAEWOO M-150 BL2
Notice: Brake fluid may damage paintwork, if spillage
onto paintwork, wash with cold water immediately.
MAB4B004
Installation procedure
1. Install the proportioning valve (1).
Tighten
Tighten the proportioning valve to 22 NSm (16 lb-ft).
2. Install the brake pipe fitting (2).
Tighten
Tighten the brake pipe fitting–to–proportioning valve
to 16 NSm (12 lb-ft).
3. Bleed the brake system. Refer to Section 4A, Hy-
draulic Brakes.
D107A504
BRAKE FLUID LEVEL SWITCH
Removal procedure
1. Remove the vacuum hose from the power booster.
Refer to Section 4C, Power Booster.
2. Remove the brake fluid level switch.
D Remove the brake fluid level switch locking system
by the flathead screwdriver (1).
D107A505
D Disconnect the electrical connector (2).
