ENGINE CONTROLS 1F–167
DAEWOO M-150 BL2
DTC P1382 – Rough Road Data Invalid (NON ABS)
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Was the check performed?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
1. Turn the ignition ON, with engine OFF.
2. Install a scan tool to the Data Link Connector
(DLC).
3. Review and record the scan tool Failure Records
data.
4. Operate the vehicle within Failure Records
conditions as noted.
5. Using the scan tool, monitor specific Diagnostic
Trouble Code (DTC) info for DTC P1382.
Does the scan tool indicate that DTC P1382 failed?
–
Go to Step 4 Go to Step 3
3
1. Check for the following conditions and repair as
needed:
2. VR sensor seal missing or damaged.
3. VR sensor mounting flanges cracked, missing, or
incorrectly installed.
Is the repair complete?
–
Go to Step 14
Go to
“Diagnostic
Aids”
4
1. Turn the ignition OFF.
2. Disconnect the VR sensor electrical connector.
3. Turn the ignition ON, with the engine OFF.
4. Observe the VR sensor value displayed on the
scan tool.
Is the VR sensor value near the specified value?
0V Go to Step 5 Go to Step 12
5
1. Jumper the 5 volt reference circuit, terminal 1 and
the VR sensor signal circuit, terminal 2 together at
the VR sensor harness connector.
2. Observe the VR sensor value displayed on the
scan tool.
Is the VR sensor value near the specified value? 4.95V Go to Step 6 Go to Step 7
6
1. Turn the ignition OFF.
2. Disconnect the Engine Control Module (ECM) and
check the sensor ground circuit for high
resistance, an open between the ECM and the
wheel speed sensor, or for a poor connection at
the terminal 85 of the ECM and repair as needed.
Is the repair complete?
–
Go to Step 14 Go to Step 10
7
Check the 5 volt reference circuit for high resistance,
an open between the ECM and the VR sensor, or a
poor connection at the terminal 55 of the ECM and
repair as needed.
Is the repair complete?
–
Go to Step 14 Go to Step 8
8
1 Turn the ignition OFF.
2. Disconnect the ECM and check the VR sensor
signal circuit for high resistance, an open, a low
voltage, or a short to the sensor ground circuit
and repair as needed.
Is the repair complete?
–
Go to Step 14 Go to Step 9
