Daewoo MATIZ - Specifications; Starter Specifications; Generator Specifications; Ignition System Specifications

ENGINE ELECTRICAL 1E–41
DAEWOO M-150 BL2
SPECIFICATIONS
STARTER SPECIFICATIONS
Application Description Unit Standard Limit
Starter Motor Type – SD 80 –
Output(Capacity) kW 0.8 –
No Load Test @ 9 volts
Drive Pinion Speed
A
RPM
150
2,000
–
Brushes Length mm (in.) 11.3–11.5
(0.445–0.453)
7.0–7.25
(0.275–0.285)
GENERATOR SPECIFICATIONS
Application Description Unit Standard Limit
Generator Type A-Type – J114D(MANDO) –Generator Type A-Type
B-Type
– J114D(MANDO)
CS114D(DAC)
–
Regulator A-Type V 14.4–15.0 –Regulator
Voltage
A-Type
B-Type
V 14.4–15.0
14.3–4.9
–
Brushes
Length
A-Type
B-Type
mm (in.) 18.5 (0.728)
20.0 (0.787)
13.5 (0.531)
14 (0.551)
Output A-Type – 12V, 65A –Output
(Capacity)
A-Type
B-Type
– 12V, 65A
12V, 65A
–
IGNITION SYSTEM SPECIFICATIONS
Application Description Unit Standard Limit
Ignition Coil Type – Closed
Magnetic Type
–
First Coil Resistance Ω 1.2$10% –
Second Coil Resistance KΩ 12.1 $15% –
Distributor Type – Optical Sensor
Type
–
Spark Plug Type Unlead – BPR5EY-11 –
RN9YC4 –
WR8DCX –
Type Lead – BPR5EY –
RN9YC –
WR8DC –
Spark Plug Gap Unlead mm (in.) 1.1 (0.043) –
1.2 (0.047) –
Lead mm (in.) 0.8 (0.031) –
Ignition Wire Ignition Wire Resistance KΩ/m 2.5–12.0 –
