ENGINE ELECTRICAL 1E–17
DAEWOO M-150 BL2
D12E513A
Installation Procedure
1. Install in the reverse order of removal.
2. Install the battery rod and cable nuts.
Tighten
D Tighten the battery rod nut to 6–8 NSm (53–71 lb-
in) (a).
D Tighten the battery cable nut to 9-12 NSm (80–106
lb-in) (b).
D12E514A
DISTRIBUTOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the air filter, resonator with snorkel assem-
bly. Refer to Section 1B, SOHC Engine Mechanical.
3. Disconnect the ignition wires and electrical connec-
tor.
D Disconnect the optical sensor connector (1).
D Disconnect the ignition wires (2).
D Remove the ignition wire clip (3).
D102E515
4. Remove the distributor.
Important: Mark on the distributor housing and case
before remove distributor (a).
D Remove the distributor bolts (1).
D Carefully remove the distributor assembly (2).
D12E516A
10–16 NSm
Installation Procedure
1. Install in the reverse order of removal.
2. Install the distributor bolts.
Tighten
Tighten the distributor bolts to 10–16 NSm (89–142 lb-
in).
