Daewoo MATIZ - 9 G-3; Rear Rocker Trim Panel

9G –14 INTERIOR TRIM
DAEWOO M-150 BL2
D109E570
REAR ROCKER TRIM PANEL
Removal Procedure
1. Remove the rear seat cushion.
D110A508
2. Remove the rear seat belt bolt on the floor.
D Remove the bolt (1).
D Remove the spacer and the spring washer (2).
D Remove the plastic protector from the seat belt an-
chor.
D109E571
3. Pry off the rear rocker trim panel.
D Remove the screws securing the rear rocker trim
panel (1).
D Remove the clip (2).
D Pry off the rear rocker trim panel (3).
D109E572
Installation Procedure
1. Install the rear rocker trim panel with the screws and
the clip.
2. Install the rear seat belt bolt on the floor.
3. Install the rear seat cushion.
