INTERIOR TRIM 9G–15
DAEWOO M-150 BL2
D19E573A
FLOOR CONSOLE
Removal Procedure
1. Remove the floor console screws.
D19E575A
2. Remove the gear shift lever boot cover and the floor
console.
D Remove the gear shift lever boot cover (1).
D Remove the screws (2).
D Remove the floor console (3).
D19E576A
Installation Procedure
1. Install the floor console.
2. Install the gear shift lever boot cover to the floor con-
sole.
3. Tighten the floor console screws.
D109E577
PARKING BRAKE CABLE COVER
Removal Procedure
1. Remove the parking brake cable cover.
D Remove the screw (1).
D Remove the cable cover (2).
To Next Page
