ENGINE CONTROLS 1F25
DAEWOO M-150 BL2
ENGINE CRANKS BUT WILL NOT RUN
Caution: Use only electrically insulated pliers when
handling ignition wires with the engine running to
prevent an electrical shock.
Caution: Do not pinch or restrict nylon fuel lines.
Damage to the lines could cause a fuel leak, result-
ing in possible fire or personal injury.
Important: If a no start condition exists, ensure the fuel
cutoff switch has not been tripped prior to further diagno-
sis.
Engine Cranks But Will Not Run
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Is the check complete.
Go to Step 2
Go to Euro
On-Board
Diagnostic
System Check
2
Crank the engine.
Does the engine start and continue to run?
System Ok Go to Step 3
3
Perform a cylinder compression test.
Is the cylinder compression for all of the cylinders at
or above the value specified?
1250 kPa
(181 psi) Go to Step 7 Go to Step 4
4
Inspect the timing belt alignment.
Is the timing belt in alignment?
Go to Step 6 Go to Step 5
5
Align or replace the timing belt as needed.
Is the repair complete?
Go to Step 2
6
Repair internal engine damage as needed.
Is the repair complete?
Go to Step 2
7
Inspect the fuel pump fuse.
Is the problem found?
Go to Step 8 Go to Step 9
8
Replace the fuse.
Is the repair complete?
Go to Step 2
9
Check for the presence of spark from all of the
ignition wires while cranking the engine.
Is spark present from all of the ignition wires?
Go to Step 23 Go to Step 10
10
1. Measure the resistance of the ignition wires.
2. Replace any of the ignition wire(s) with a
resistance above the value specified.
3. Check for the presence of spark from all of the
ignition wire.
Is spark present from all of the ignition wires? 5 k Go to Step 2 Go to Step 11
11
1. Turn the ignition OFF.
2. Disconnect the crankshaft position (CKP) sensor
connector.
3. Turn the ignition ON.
4. Measure the voltage between following terminals:
D Terminal 1 and 3 of the CKP sensor connector.
D Terminal 2 and 3 of the CKP sensor connector.
D Terminal 1 of the CKP sensor connector and
ground.
D Terminal 2 of the CKP sensor connector and
ground.
Are the voltage measure within the value specified? 0.4 V Go to Step 13 Go to Step 12
