ENGINE CONTROLS 1F–163
DAEWOO M-150 BL2
D A history DTC will clear after 40 consecutive warm up
cycles without a fault.
D Using the scan tool can clear DTC(s).
D Disconnecting the ECM battery feed for 10 seconds.
DIAGNOSTIC AIDS
Check and correct any abnormal engine noise before
using the diagnostic table.
Any circuitry that is suspected as causing engine noise
complaint should be thoroughly checked for the follow-
ing conditions :
D Backed-out terminals.
D Improper mating.
D Broken locks.
D Improperly formed.
D Damaged terminals.
D Poor terminal-to-wire connections.
D Physical damage to the wiring harness.
DTC P0352 – Ignition Signal Coil B Fault
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Is the system check complete?
–
Go to Step 2
Go to
“On-Board
Diagnostic
System Check”
2
Check for a faulty connection or a damaged terminal
3 at the ignition coil.
Is a problem found?
–
Go to Step 8 Go to Step 3
3
Check for a faulty connection or a damaged terminal
32 at the engine control module(ECM) connector.
Is the problem found?
–
Go to Step 8 Go to Step 4
4
1. Turn the ignition switch to LOCK.
2. Disconnect the ECM.
3. Check the ignition control circuit for a short to
ground
Is the problem found?
–
Go to Step 8 Go to Step 5
5
Check the ignition control circuit for a short to
battery voltage.
Is the problem found?
–
Go to Step 8 Go to Step 6
6
Check for an open in the ignition control.
Is the problem found?
–
Go to Step 8 Go to Step 7
7
Replace the ECM.
Is the replacement complete?
–
Go to Step 8
–
8
1. Using the scan tool, clear the Diagnostic Trouble
Codes(DTCs).
D Start the engine and Idle at normal operating
temperature.
D Operate the vehicle within the conditions for
setting this DTC as specified in the supporting
text.
Does the scan tool indicate that this diagnostic ran
and passed?
–
Go to Step 9
–
9
Check if any additional DTCs are set.
Are any DTCs displayed that have not been
diagnosed?
–
Go to
Applicable DTC
table
System OK
