Daewoo MATIZ - Stoplamps and Interior Courtesy Lamp

LIGHTING SYSTEMS 9B–5
DAEWOO M-150 BL2
STOPLAMPS AND INTERIOR COURTESY LAMP
Condition Probable Cause Correction
Stoplamps Do Not Work. D Fuse F5 is blown. D Replace the fuse F5.
D The open circuit or a short circuit
between the fuse F11 and the
terminal 2 of the stoplamps switch
connector (For vehicle equipped
with M/T).
D Repair or Replace the wiring
harness.
D Faulty stoplamp switch. D Replace the stoplamp switch.
D The open circuit or a short circuit
between the terminal 1 of the
stoplamp switch connector and
the terminal 3 of the stoplamps
connector (For vehicle equipped
with M/T).
D Repair or Replace the wiring
harness.
D Stoplamp bulb is blown. D Replace the stoplamp bulb.
D The open ground (G401, G402)
circuits.
D Repair or Replace the open
ground circuit.
Interior Courtesy Lamp Does
Not Work.
D The open circuit or a short circuit
in the power supply circuit to the
fuse Ef2.
D Repair or Replace the wring
harness.
D Fuse Ef2 is blown. D Replace the fuse Ef2.
D The open circuit or a short circuit
between the fuse Ef2 and the fuse
F11.
D Repair or Replace the wiring
harness.
D Fuse F11 is blown. D Replace the fuse F11.
D The open circuit or a short circuit
between the fuse F11 and the
terminal 1 of the interior courtesy
lamp connector.
D Repair or Replace the wiring
connector.
D Interior courtesy lamp bulb is
blown.
D Replace the bulb.
D Faulty interior courtesy lamp. D Replace the interior courtesy
lamp.
