Daewoo MATIZ - Warning Lamp Operation; Brake System Fault

HYDRAULIC BRAKES 4A–5
DAEWOO M-150 BL2
WARNING LAMP OPERATION
This brake system uses a BRAKE warning lamp located
in the instrument panel cluster. When the ignition switch
is in the III position, the BRAKE warning lamp should
glow and then go OFF when the ignition switch returns
to the II position.
The following conditions will activate the BRAKE lamp:
D Parking brake applied. The light should be on when-
ever the parking brake is applied and the ignition
switch is II.
D Low fluid level. A low fluid level in the master cylinder
will turn the BRAKE lamp ON.
BRAKE SYSTEM FAULT
ÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁ
Condition
ÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁ
Probable cause
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Correction
Brake Warning Lamp ON
D Brake fluid leaks. D Repair the leaks or add th fluid.
D Parking brake switch shorted to
ground.
D Repair the short ground.
D Faulty the fluid level sensor. D Replace the sensor.
Stoplamp ON
D Faulty the stoplamp switch. D Replace the stoplamp switch.
D Push rod length is short. D Adjust the push rod length of the
power booster.
D Stoplamp switch circuit shorted to
battery.
D Repair or Replace the wiring harness.
Poor Braking
D Brake fluid lacks or leaks. D Repair the leaks or add the fluid.
D Brake fluid contamination. D Replace the fluid.
D Air in the brake system. D Bleed the brake system.
D Damaged brake lines. D Replace the brake lines.
D Damaged vacuum hose or faulty
check valve.
D Replace the vacuum hose or check
value.
Dragging Brake
D No free play at the brake pedal. D Adjust the free play.
D Weakened the brake pedal return
spring.
D Replace the return spring.
D Faulty master cylinder. D Replace the master cylinder.
D Air in the brake system. D Bleed the brake system.
Pedal Over Stroke
D Brake fluid lacks or leaks. D Repair the leaks or add the fluid.
D Poor adjustment of the brake pedal
free play.
D Adjust the push rod length of the
power booster.
