ENGINE CONTROLS 1F–47
DAEWOO M-150 BL2
Ignition System Check (Cont’d)
Step Action Value(s) Yes No
21
Measure the voltage between the CKP sensor
connector terminal 2 and ground.
Is the voltage within the value specified? 0.95–1.10 V Go to Step 18 Go to Step 22
22
Check the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24 for an
open or short.
Is the problem found?
–
Go to Step 23 Go to Step 11
23
Repair the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24.
Is the repair complete?
–
System OK
–
24
1. Turn the ignition OFF.
2. Connect a test light between the EI system
ignition coil connector terminal 2 and ground.
3. Turn the ignition ON.
Is the test light on?
–
Go to Step 27 Go to Step 25
25
Check for an open in the wiring between the EI
system ignition coil connector, terminal 1 and the
main relay connector terminal 87.
Is the problem found?
–
Go to Step 26
Go to “Main
Relay Circuit
Check”
26
Repair the open in the wiring between the EI system
ignition coil connector terminal 1 and the main relay
connector terminal 87.
Is the repair complete?
–
System OK
–
27
Check for a damage in the terminal of the EI system
ignition coil connector and repair as needed.
Is the repair complete?
–
System OK
–
To Next Page
