9H –8 SEATS
DAEWOO M-150 BL2
D109B533
5. Remove the recliner cover.
D Remove the screws (1).
D Remove the recliner cover (2).
D109B538
6. Remove the seat cushion.
D Remove the recliner bolts on the seat cushion (1).
D Remove the seatback bolt (2).
D Remove the seat cushion (3).
D109B536
Installation Procedure
1. Install the seat cushion with the seatback bolt and the
recliner bolts.
D109B537
2. Install the recliner cover and the recliner knob with the
screws.
3. Install the seat belt buckle. Refer to Section 8A, Seat
Belts.
4. Install the front seat assembly. Refer to “Front Seats”
in this section.
5. Connect the negative battery cable.
