9H –10 SEATS
DAEWOO M-150 BL2
D109B541
Installation Procedure
1. Install the seat cushion cover with the hog rings.
D109B540
2. Install the guide rail with the bolts.
3. Install the front seat cushion. Refer to “Front Seat
Cushion” in this section.
4. Connect the negative battery cable.
D109B542
REAR SEATBACK
Removal Procedure
1. Remove the rear seatback.
D Remove the rear seatback lock by pulling the lock
knob upward (1).
D Remove the seatback hinge bolts (2).
D Remove the rear seatback (3).
D19B543A
23–28 NSm
Installation Procedure
1. Install the rear seatback with the hinge bolts.
Tighten
Tighten the hinge bolts to 23–28 N.m (17–21 lb-ft).
a. Rear seatback hinge bolt.
2. Press the lock knob.
To Next Page
