BUMPERS AND FASCIAS 9O–7
DAEWOO M-150 BL2
D19C511A
3. Remove the fascia bolts from the rear bumper brack-
et.
D19C512A
4. Lower the vehicle.
5. Remove the fascia.
D Remove the nuts in the luggage compartment (1).
D Remove the screws (2).
D Remove the fascia (3).
D19C513A
Installation Procedure
Notice: Dissimilar metals in direct contact with each
other may corrode rapidly. Make sure to use the correct
fasteners to prevent premature corrosion.
1. Install the fascia.
2. Install the fascia upper nut.
a. The fascia upper nut.
3. Install the fascia upper screws
b. The fascia upper screws.
D19C514A
4. Raise and suitably support the vehicle.
5. Install the fascia lower bolts.
c. The fascia lower bolts.
6. Lower the vehicle.
